Cylinder heads Chev SB E-Street alloy complete (pair) straig


No Brand
Part No: E5089
Cylinder heads Chev SB E-Street alloy complete (pair) straight plug 64cc chamber 2.02 intake 1.60 exhaust valves 185cc intake runner (May require different length pushrods & use head bolt washers) Edelbrock E Street 5089
Additional Notes: ***Check pushrods for clearance, may need adjustable guide plates or milling***
Availability:In Stock
$2,879.52 (incl Gst)
$2,733.10 (incl Gst)

Qty:

Add To
Instock Quantity


  Your Price $2,376.61
Edelbrock Small-Block Chevy E-Street Cylinder Heads 64cc

The Edelbrock #5089 E-Street cylinder heads are designed for use with 1955-1986 Small-Block Chevy applications. The Edelbrock E-Street cylinder heads offer American made quality and affordable performance. E-Street cylinder heads feature as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The entry-level street performance 1955-86 applications.
Designed for use with modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency.

Designed for use with hydraulic flat tappet camshafts only, not compatible with hydraulic roller camshafts

Use with Hydraulic Flat Tappet Camshafts .550" max lift. (NOT Compatible with Hydraulic Roller Camshafts)

Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat.

Requires hardened pushrods.

All E-Street Cylinder Heads are sold in pairs

Dyno tests showed a gain of 16 hp and 11 ft-lbs of torque over our overseas competitor

CNC Ported: No
Combustion Chamber Volume: 64.0 cc
Deck Height: 9.025 in
Deck Thickness: 0.562 in
Exhaust Valve Diameter: 1.600 in
Guide Plates Included: Yes
Intake Runner Volume: 185.0 cc
Material: Aluminum
Push Rod Diameter: 0.312 in
Rocker Stud Diameter: 0.375 in
Valve Angle: 23 deg
Valve Spring Diameter: 1.460 in
Valve Spring Maximum Lift: 0.550 in
Valve Stem Diameter: 0.341 in



Part #
Description
Back Order
Your Price
Qty

ARP134-3601
ARP134-3601
Head bolt kit Chev SB OEM cast & aluminium 6 point hex High
No
$189.52 (incl Gst)
ARP134-4001
ARP134-4001
Head stud kit Chev SB OEM cast & aluminium 6 point hex nuts
No
$432.47 (incl Gst)
CS8510VR
CS8510VR
Conversion set Chev 305ci, 350ci SB V8 1986-1995 Victor Rein
No
$93.20 (incl Gst)
E2324
E2324
Fender cover Edelbrock Racing logo 22 x 34" length, PVC foam
No
$100.36 (incl Gst)
FEL1144
FEL1144
Head gasket Chev SB 262-400 V8 4.200 bore .041 thickness 9.3
No
$174.96 (incl Gst)
HG350A
HG350A
Head gasket Chev 283ci, 302ci, 307ci, 327ci, 350ci SB printo
No
$25.73 (incl Gst)
MCB663 STD
MCB663 STD
Rod bearing set Chev 305ci 327ci large journal 350ci 400ci S
No
$79.78 (incl Gst)
MMS909 STD
MMS909 STD
Main bearing set Chev 305ci, 327ci large journal, 350ci SB S
No
$114.77 (incl Gst)
PSLH345DCP STD
PSLH345DCP STD
Piston set Chev 350ci, 5.7L SB flat top 4 valve reliefs Hype
No
$343.64 (incl Gst)
Install Instructions
Installation Instructions










Fitment
